15.7" Round LCD Display Screen - High Resolution Circular LCD Panel for Smart Home, Digital Signage, and Industrial Control Applications

$1099.45 $1999 -45% OFF

Free shipping on all orders over $50

7-15 days international

6 people viewing this product right now!

30-day free returns

Secure checkout

66253054

Guranteed safe checkout

HD: HD full-view LCD display, ultra-HD resolution
Ultra-thin: Industrial-grade appearance, reasonable design, stable and strong
Performance: Internal heat dissipation adopts convection method, long-term load work without worry
System: Powerful 3568 motherboard solution, equipped with Android 11 operating system
Appearance: Unique round eye-catching shape
Applicable: Various sizes, various shapes, suitable for various scenarios
Customization: Various lengths and widths, various parameters, source factory, fully equipped, support OEM/ODM

PARAMETERS
The Screen	Model	15.7"-YXLCD
	LCD screen specifications	Brand new original LCD panel
	Viewing angle	89/89/89/89
	Color	16.7M, 72% NTSC
	Refresh rate	60HZ
	Display area	400*400 mm
	Screen size	15.7‘’
	Brightness	700cd/m2
	Contrast ratio	1000:1(TYPIC, different OC contrast ratios vary, subject to actual conditions)
	Lifespan	50000H
	Resolution	960*960
Control Board	Chip	RK3568
	CPU	Quad-core ARM Cortex-A55, 2.0G
	RAM	2G
	System	Android 11
	GPU	Mali-G52 Quad-core
	ROM	16G (customizable)
	Interface	Headphones, HDMI out, RJ45, HDMI IN, USB 3.0*2, DC-IN
	Network	Gigabit wired network port; support 2.4G wireless network access (2.4G/5G dual-band optional); Bluetooth; support 3G/4G wireless module
Physical Features	Frame material	Sheet metal/profile
	Body color	Black
	Frame color	Black and other options available
	Tempered glass	Default: None, optional 3mm explosion-proof tempered glass
	Dimensions	Φ453 * 61.2mm
Touch Function (Optiona)	Touch type	Capacitive touch
	Minimum recognition	6mm
	Writing surface screen hardness	7H
	Response time	25ms
	Number of touch points	20 points
	Input method	Finger, capacitive pen
	Communication method	Full-speed USB
	Touch accuracy	±1.5mm (more than 90% touch area)
Power Consumption	Power input voltage	DC 12V
	Device power	≤50W
	Standby power	<1W
Working Environment	Input voltage	AC110-220V/DC12-24V
	Usage environment	Temperature ‐0℃~55℃/Humidity 10%RH~90%RH
	Standby power consumption	≤1W
	Storage environment	Temperature ‐5℃~60℃/Humidity 10%RH~90%RH
Language	OSD	English / Chinese
Accessories	Power cord1, Wall Hanging Hardware 1

Lead Time: The product take 15-20days to make .
PackingThe LCD Screen will be packed in one-time hard carton box for shipping.
Free Shipping
For shipping, the price on this page is include free shipping by AIR +Delivery to door by truck. It's by flight + UPS delivery to door which in regular would take around 12-15days at least in transportation after flight departure;
DDP TERM (all fee included) except the to destination country that this shipping service is not available, then we will contact the buyer if this clause does not apply to his country.
